| Czujnik obrazu | 2 × 1/2.5" Progressive Scan CMOS |
| Maksymalna rozdzielczość | 3632 × 1632 |
| Min. Oświetlenie | Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light |
| Czas migawki | 1/3 s to 1/100,000 s |
| Regulacja kątowa | Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360° |
| Obiektyw | Typ obiektywu | Fixed focal lens, dual lens, 2.8 mm |
| Ogniskowa i FOV | 2.8 mm, horizontal FOV: 180°, vertical FOV: 81° |
| Mocowanie obiektywu | M12 |
| Rodzaj przysłony | Fixed |
| Przysłona | F1.0 |
| Głębia pola | 2 m to ∞ |
| DORI | DORI | 2.8 mm, D: 45 m, O: 17.5 m, R: 9 m, I: 4.5 m |
| Oświetlacz | Suplement typu światła | Białe światło |
| Suplement Light Range | Up to 40 m |
| Inteligentne światło uzupełniające | Yes |
| Wideo | Główny strumień | 50 Hz: 20 fps (3632 × 1632) 60 Hz: 20 fps (3632 × 1632) |
| Podstrumień | 50 Hz: 20 fps (1200 × 536, 960 × 432)60 Hz: 20 fps (1200 × 536, 960 × 432) |
| Kompresja wideo | Main stream: H.265+/H.265/H.264+/H.264Sub-stream: H.265/H.264/MJPEG |
| Video Bitrate | 32 Kbps to 16 Mbps |
| H.264 | Baseline Profile,Main Profile,High Profile |
| H.265 | Main Profile |
| Kontrola szybkości transmisji | CBR,VBR |
| Skalowalne kodowanie wideo (SVC) | H.264 and H.265 encoding |
| Region zainteresowania (ROI) | 1 fixed region(s) for main stream |
| Audio | Typ dźwięku | Mono sound |
| Kompresja dźwięku | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Szybkość transmisji audio | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Szybkość próbkowania audio | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Filtrowanie szumów środowiska | Yes |
| Sieć | Protokoły | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, Websocket, Websockets |
| Jednoczesny widok na żywo | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK |
| Użytkownik/host | Up to 32 users3 user levels: administrator, operator, and user |
| Bezpieczeństwo | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address) |
| Pamięć sieci | NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Klient | iVMS-4200,Hik-Connect,Hik-Central |
| Przeglądarka internetowa | Plug-in required live view: IE 10, IE 11,Plug-in free live view: Chrome 57.0+, Firefox 52.0+,Local service: Chrome 57.0+, Firefox 52.0+ |
| Obraz | Przełącznik parametrów obrazu | Yes |
| Ustawienia obrazu | Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
| Tryb dzień/noc | Day,Night,Auto,Schedule |
| Szeroki zakres dynamiczny (WDR) | 130 dB |
| SNR | ≥ 52 dB |
| Ulepszenie obrazu | BLC,HLC,3D DNR |
| Interfejs | Interfejs Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
| Wbudowany mikrofon | Yes |
| Wbudowany głośnik | Max. power consumption: 1 W, max. sound pressure level: 10 cm: 97 dB. |
| Audio | 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Alarm | 1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A) |
| Przycisk reset | Yes |
| Wydarzenie | Podstawowe zdarzenie | Motion detection (support alarm triggering by specified target types (human and vehicle)),alarm input and output,flashing alarm light output, audible alarm output, exception |
| Inteligentne wydarzenie | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)),Scene change detection |
| Połączenie | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,white light flashing |
| Ogólny | Moc | 12 VDC ± 25%, 0.88 A, max. 10.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W |
| Materiał | Front cover: metal, body: metal, bracket: metal |
| Wimiary | 118.6 mm × 105.1 mm × 306.5 mm (4.7" × 4.1" × 12.1") |
| Wymiary opakowania | 405 mm × 190 mm × 180 mm (16" × 7.5" × 7.1") |
| Waga | Approx. 1400 g (3.1 lb.) |
| Waga z opakowaniem | Approx. 2100 g (4.6 lb.) |
| Warunki przechowywania | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Warunki uruchomienia i pracy | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Język | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Funkcja ogólna | Anti-banding, heartbeat, mirror, flash log, pixel counter |
| Migające światło | Yes |
